GPA Type Automatic Sewage Grinder Pump
DESIGNED FOR PUMPING OF WASTEWATER WITH TOILET WASTE.
Capability of Connecting with TOS-GP Type Guid Rail Kit.
Power: 1.5HP and 2HP
Motor: 2 Poles
Built-in Automatic Float Key Switch.
The sewage grinder pump reduces waste content to fine slurry, pumped through small-diameter pipes.
The Showfou GPA type – automatic macerator submersible pump, known as sewage grinder pump or cutter pump, has built-in the advanced integrated grinding mechanism which is particularly well-suited for use with liquids that may contain filaments, plastic bags, long fibers, rubber material, etc.
The grinding mechanism is composed of a fixed shredder ring and a rotating grinder made by hard Chromium-Molybdenum alloy steel “SCM440” that is highly resistant to the abrasion. There are 27 cutting edges on the fixed part. Then the two poles high torque motor will provide more than 80,000 shredding actions every minute to perform an optimum shredding performance.
The automatic macerator submersible pump type GPA is specially designed for pumping untreated wastewater from domestic, commercial or municipal sources. The high discharge pressure enables transfer of wastewater over longer distances.
Construction on the GPA type macerator submersible is heavy duty cast iron and Stainless Steel. The GPA type macerator submersible pumps are free standing or can be mounted on guide rails for use in packaged pumping stations
Stainless steel motor housing
Cast iron pump housing and volute
Cast iron impeller
The triplex seals – Double mechanical seal plus an oil seal to isolate the motor from the sewage.
Unique Epoxy Cable Sealing Base ensures 100% capability to block the water vapor from entering the motor even the cable breaks.
Using heavy-duty dual ball bearing on the bottom of the motor to support the axial push.
The manual version the GPA type sewage grinder pump is also available.
Ideal for sewage, industrial & groundwater drainage installation in the following fields.
Sewage pumping stations.
Sewage treatment plants.
Septic tanks.
Collecting & settling sumps.
Package sewage stations and portable sewage pumping.
Anywhere drainage of dirty water with rags mixed in.
Most nuisance water drainage if organic soilds are present.
"Type GPA"
DESIGNED FOR PUMPING OF WASTEWATER WITH TOILET WASTE.
Capability of Connecting with TOS-GP Type Guid Rail Kit.
Power: 1.5HP and 2HP
Motor: 2 Poles
Built-in Automatic Float Key Switch.
The sewage grinder pump reduces waste content to fine slurry, pumped through small-diameter pipes.
The Showfou GPA type – automatic macerator submersible pump, known as sewage grinder pump or cutter pump, has built-in the advanced integrated grinding mechanism which is particularly well-suited for use with liquids that may contain filaments, plastic bags, long fibers, rubber material, etc.
The grinding mechanism is composed of a fixed shredder ring and a rotating grinder made by hard Chromium-Molybdenum alloy steel “SCM440” that is highly resistant to the abrasion. There are 27 cutting edges on the fixed part. Then the two poles high torque motor will provide more than 80,000 shredding actions every minute to perform an optimum shredding performance.
The automatic macerator submersible pump type GPA is specially designed for pumping untreated wastewater from domestic, commercial or municipal sources. The high discharge pressure enables transfer of wastewater over longer distances.
Construction on the GPA type macerator submersible is heavy duty cast iron and Stainless Steel. The GPA type macerator submersible pumps are free standing or can be mounted on guide rails for use in packaged pumping stations
FEATURES
Stainless steel motor housing
Cast iron pump housing and volute
Cast iron impeller
The triplex seals – Double mechanical seal plus an oil seal to isolate the motor from the sewage.
Unique Epoxy Cable Sealing Base ensures 100% capability to block the water vapor from entering the motor even the cable breaks.
Using heavy-duty dual ball bearing on the bottom of the motor to support the axial push.
The manual version the GPA type sewage grinder pump is also available.
APPLICATIONS
Ideal for sewage, industrial & groundwater drainage installation in the following fields.
Sewage pumping stations.
Sewage treatment plants.
Septic tanks.
Collecting & settling sumps.
Package sewage stations and portable sewage pumping.
Anywhere drainage of dirty water with rags mixed in.
Most nuisance water drainage if organic soilds are present.
