KHQ Type Cast Stainless Dewatering Pump(SCS13)
A CORROSION-RESISTANT PUMP FOR HANDLING AGGRESSIVE AND CORROSIVE LIQUIDS.
Power: 2 ~15 HP
Motor: 2 Poles
ALL WETTED PARTS ARE SCS13(#304)STAINLESS STEEL INVESTMENT CASTING .
MECHANICAL SEAL ADOPTS HIGHLY WEAR-RESISTANT SIC/SIC WITH VITON O-RING.
The Wear Parts are made of casting stainless #SCS13, and the water-cooling design for longer servicing life
Top discharge for easy piping on site, and water cooling design can remove the water to much lower level.
Pump Casing: Rugged SCS13 (#304) stainless investment casting with a smooth surface finish.
Impeller: Statically and dynamically balanced, semi-open type impeller design, prevents clogging by mud, sand, etc.
Suction Cover: Easily replaceable.
Oil-lubricated Double Mechanical Seals (highly wear-resistant SiC/SiC with Viton) together with a separate Viton Oil Seal.
The whole unit is equipped with Viton O-ring.
The Motor Casing and outer casing adopt stainless steel sheet material, greatly reduces the pump’s weight and easy to carry for the work.
Quality IP68 motor with water cooling design, very suitable for continuous duty.
Single phase model with built-in thermal protector in motor, preventing any burning damage to the motor.
Very good for pumps with clean non-volatile liquids without solids or fibers in below applications as :
Dewatering containing acidic fluid.
Dyeing industry.
Mariculture.
Chemical plating.
Irrigation and other general corrosive media.
"Type KHQ"
A CORROSION-RESISTANT PUMP FOR HANDLING AGGRESSIVE AND CORROSIVE LIQUIDS.
Power: 2 ~15 HP
Motor: 2 Poles
ALL WETTED PARTS ARE SCS13(#304)STAINLESS STEEL INVESTMENT CASTING .
MECHANICAL SEAL ADOPTS HIGHLY WEAR-RESISTANT SIC/SIC WITH VITON O-RING.
The Wear Parts are made of casting stainless #SCS13, and the water-cooling design for longer servicing life
FEATURES
Top discharge for easy piping on site, and water cooling design can remove the water to much lower level.
Pump Casing: Rugged SCS13 (#304) stainless investment casting with a smooth surface finish.
Impeller: Statically and dynamically balanced, semi-open type impeller design, prevents clogging by mud, sand, etc.
Suction Cover: Easily replaceable.
Oil-lubricated Double Mechanical Seals (highly wear-resistant SiC/SiC with Viton) together with a separate Viton Oil Seal.
The whole unit is equipped with Viton O-ring.
The Motor Casing and outer casing adopt stainless steel sheet material, greatly reduces the pump’s weight and easy to carry for the work.
Quality IP68 motor with water cooling design, very suitable for continuous duty.
Single phase model with built-in thermal protector in motor, preventing any burning damage to the motor.
APPLICATIONS
Very good for pumps with clean non-volatile liquids without solids or fibers in below applications as :
Dewatering containing acidic fluid.
Dyeing industry.
Mariculture.
Chemical plating.
Irrigation and other general corrosive media.
