BL Type Turbo Blower with Flow Regulating Disc.
DESIGNED FOR LOW PRESSURE AND HIGH FLOW APPLICATIONS
Power: 0.25, 0.5, 1, 2, 3, 5HP
Motor: 2 Poles
Motor - TEFC IP54 Grade F Insulation
Permitted maximum ambient temperature is 40ēC
BP type turbo blowers feature direct drive motors from 0.5 HP to 5 HP, and provide a maximum pressure of 300 mmAq, and a maximum air capacity of 35 CMM. Showfou BP Type centrifugal turbo blower has a Large flow, lower noise and high efficiency due to special impeller design and is designed for easy installation with versatile capabilities for vacuum or pressure operation.
Light Weight Aluminum alloy housing
Long Service life aluminum construction for excellent heat dissipation.
Low Noise and Vibration- Computerized balancing of components. .
CNC manufacturing assures high-accuracy tolerances for peak performance..
TEFC enclosure eliminates atmospheric contamination of motor winding and bearings.
The turbo blower without the flow regulating disc. on the inlet : Type BP is also available.
Printing Machines.
Dust Collectors.
Textile Machines.
Woodworking Machines.
Grain Elevators.
Incinerators.
Dryer Machines.
Plastic Extruders.
Burning Machines.
"Type BL"
DESIGNED FOR LOW PRESSURE AND HIGH FLOW APPLICATIONS
Power: 0.25, 0.5, 1, 2, 3, 5HP
Motor: 2 Poles
Motor - TEFC IP54 Grade F Insulation
Permitted maximum ambient temperature is 40ēC
BP type turbo blowers feature direct drive motors from 0.5 HP to 5 HP, and provide a maximum pressure of 300 mmAq, and a maximum air capacity of 35 CMM. Showfou BP Type centrifugal turbo blower has a Large flow, lower noise and high efficiency due to special impeller design and is designed for easy installation with versatile capabilities for vacuum or pressure operation.
FEATURES:
Light Weight Aluminum alloy housing
Long Service life aluminum construction for excellent heat dissipation.
Low Noise and Vibration- Computerized balancing of components. .
CNC manufacturing assures high-accuracy tolerances for peak performance..
TEFC enclosure eliminates atmospheric contamination of motor winding and bearings.
The turbo blower without the flow regulating disc. on the inlet : Type BP is also available.
APPLICATIONS:
Printing Machines.
Dust Collectors.
Textile Machines.
Woodworking Machines.
Grain Elevators.
Incinerators.
Dryer Machines.
Plastic Extruders.
Burning Machines.
